See a GLN panel on your own wall

GLN heats and cools with slim aluminium panels fed by water: no vents, no ducts, and no fan or compressor in the room. Pick a room and a size; the panel is drawn to scale.

Choose a room

Five sample rooms, or a photo of your own wall taken straight on.Drag the panel in the photo to move it along the wall.

Room

How big is the room?

20 m²
Seen from above. Each square is 9 m², about one 600 × 1800 panel.
Panels in this room
2
Recommended for 20 m²: 2

Demo rule: about one 600 × 1800 panel for every 9 m². Big windows, a top floor or west sun push the number up; a survey sets it.

Size and mount

Width (mm)
Height (mm)
Mount

Stands on two slim feet, 6 cm off the wall.

Each panel: about 420 W cooling and 510 W heating (demo figures).

Finish

Finish

Anodised. Natural anodised aluminium with a soft sheen.

Screens shift colour. See the real samples at the showroom before you decide.

Your configuration

Room
Dining corner
Floor area
20 m²
Panels
2 × 600 × 1800 mm
Mount
Free-standing
Finish
Anodised
Each panel
420 W cooling, 510 W heating
For the room
840 W cooling, 1,020 W heating
Panels and fitting
¥9,560 – ¥11,460

Demo prices and outputs. The outdoor heat pump is sized for the whole home and quoted after a survey.

Where should we send it?

2 × 600 × 1800 mm, Anodised¥9,560 – ¥11,460 demo

What you’re choosing

Three choices shape a panel. Size sets how much heat it moves; mount and finish decide how it sits in the room.

Size

Four widths and three heights. Output grows with the front area: a 600 × 1800 panel gives about 420 W of cooling and 510 W of heating. A 1200 × 1800 panel gives twice that.

400, 600, 900, 1200 mm wide
1200, 1500, 1800 mm tall
90 mm from the wall to the front edge

Output figures on this page are demo figures.

Door, 2.1 m 400 600 900 1200 180015001200
All twelve sizes to scale next to a 2.1 m door. The filled one is the size in your configuration.

Mount

Free-standing panels stand on two slim feet about 6 cm off the wall. Useful where a wall shouldn’t take fixings.

Wall-mounted panels hang 15 cm above the floor on brackets you don’t see from the room.

Either way the water pipes come down inside the wall from the ceiling and meet the panel at a single fitting. Nothing runs along the wall.

Free-standing 6 cm off the wall 90 mm Pipes inside the wall Single fitting Two slim feet Wall-mounted 4 cm off the wall Hidden brackets Single fitting 15 cm
Side views, to scale. Flow and return pipes stay inside the wall and meet the panel at one fitting.

Finish

Five powder coats and natural anodised aluminium, or a colour matched to your wall. The fins are the same whatever the colour, so the finish changes nothing about output.

Custom colours add ¥450 per panel (demo price).

  • ChalkWarm white. Almost vanishes on a white wall.
  • FogPale grey. Reads as part of the wall.
  • AnodisedBare aluminium with a soft sheen.
  • SageGrey-green. Calm next to wood.
  • SandWarm beige for warm-toned rooms.
  • GraphiteDeep grey. A panel you mean to show.

How many panels?

About one 600 × 1800 panel for every 9 m² of floor.

A rough demo rule for a first idea. Smaller panels count by front area, so it takes three 400 mm panels to do the work of two 600 mm ones.

Panels needed at 1800 mm tall (demo rule)
Floor area400 wide600 wide900 wide1200 wide
10 m²2111
15 m²3211
20 m²3221
25 m²4322
30 m²5322
40 m²7532

What changes the number

  • Large or west-facing windows, which let in afternoon sun.
  • A top floor with the roof above it.
  • Open plans joined to a hallway or stairs.
  • Ceilings well above 2.8 m.

Wuhan has long, hot summers and cold, damp winters, so we size for both seasons. A home survey measures each room and sets the real count.

Why the surfaces matter

How warm a room feels is roughly the average of the air temperature and the temperature of the surfaces around you (ASHRAE 55, ISO 7730). Panels work on the surfaces, not the air.

See the finishes in person

Colour on a screen is an estimate. In the Wuhan showroom, working panels stand in all six finishes. Stand next to one in cooling mode, then in heating mode, and bring a paint chip if you want a colour matched.

Address
2F, 88 Zhongbei Road, Wuchang District, Wuhan
Open
Tuesday to Sunday, 10:00 to 18:00

Book a visit

Time

Questions before a quote

Does GLN do both heating and cooling?

Yes. An outdoor heat pump warms the water in winter and cools it in summer. The water runs through the panels, the room’s surfaces settle at the right temperature, and heat moves by radiation instead of blown air.

Where do the pipes go?

They come down inside the wall from the ceiling and join the panel at a single fitting. You don’t see pipes on the wall, and there are no vents or ducts anywhere in the system.

What about condensation in summer?

No condensation water appears indoors. Ask us to show you how in the showroom.

Is it quiet at night?

There is no fan and no compressor in the room, so there is no fan noise and no air blown at you. The outdoor unit has a compressor and sits outside, like any heat pump.

Can a panel match my wall colour?

Yes. Pick “Custom” in the finish step and give us a colour code or a paint chip. We powder-coat to match, for ¥450 per panel (demo price).

How long does installation take?

In a renovation the pipes go in while the walls are open. In a finished home we survey first and plan the pipe route. A typical home takes two to four days (demo figure).

Is the price in the summary a quote?

No. It is a demo range for the panels and their fitting. The outdoor heat pump is sized for the whole home, so it is quoted after the survey.
